MY FORCEDOOR

Safety receiver

F-RV

F-RV

Description:

F-RV is a simplified smart door control with core wireless sensor communication functions. With a more compact design, F-RV is designed to provide reliable wireless security solutions for garage/industrial doors and other occasions, especially suitable for application scenarios with limited space or no remote control required.



Parameter

Radio technology:                              Trio-Frequency technology

Frequency:                                         Multi from 409.025 MHz – 458.4 MHz

Signal modulation:                             FSK

Signal range:                                     20 meters

Power supply:                                   12-24 V AC/DC

Number of relays:                              3 relays

Safety receiver modular:                    Built-in

NC/NO:                                              Adjustable

Operating temperature:                     -20°C ~ +60°C
